圆柱滚子轴承

基本尺寸			基本额定载荷		轴承类型	轴承图片	型号
			dynamic	static	Type	Images	Model
d[mm]	D[mm]	B[mm]	C[kN]	C₀[kN]
30	90	100	62.7	85	圆柱滚子轴承		PWKR 90.2RS
30	90	100	38	76.5	圆柱滚子轴承		KR 90 PPA
35	90	100	78.1	102	圆柱滚子轴承		NUKRE 90 A
30	90	100	78.1	102	圆柱滚子轴承		NUKR 90 XA
30	90	100	47.3	122	圆柱滚子轴承		KRV 90 PPA
30	90	100	47.3	122	圆柱滚子轴承		KRV 90 PPXA
35	90	100	47.3	122	圆柱滚子轴承		KRVE 90 PPA
30	90	100	38	76.5	圆柱滚子轴承		KR 90 B
35	90	100	62.7	85	圆柱滚子轴承		PWKRE 90.2RS
30	90	100	78.1	102	圆柱滚子轴承		NUKR 90 A
30	90	100	38	76.5	圆柱滚子轴承		KR 90 XB
35	90	100	38	76.5	圆柱滚子轴承		KRE 90 PPA
35	80	100	45.7	114	圆柱滚子轴承		KRVE 80 PPA
35	80	100	57.2	73.5	圆柱滚子轴承		PWKRE 80.2RS
30	80	100	36.9	72	圆柱滚子轴承		KR 80 B
30	80	100	36.9	72	圆柱滚子轴承		KR 80 PPA
30	80	100	57.2	73.5	圆柱滚子轴承		PWKR 80.2RS
30	80	100	69.3	86.5	圆柱滚子轴承		NUKR 80 A
35	80	100	69.3	86.5	圆柱滚子轴承		NUKRE 80 A
30	80	100	45.7	114	圆柱滚子轴承		KRV 80 PPA
35	80	100	36.9	72	圆柱滚子轴承		KRE 80 PPA
30	80	100	45.7	114	圆柱滚子轴承		KRV 80 PPXA
30	80	100	36.9	72	圆柱滚子轴承		KR 80 XB
30	80	100	69.3	86.5	圆柱滚子轴承		NUKR 80 XA
24	72	80	26	48	圆柱滚子轴承		KR 72 B
24	72	80	45.7	58.5	圆柱滚子轴承		NUKR 72 A
24	72	80	33	80	圆柱滚子轴承		KRV 72 PPXA
24	72	80	26	48	圆柱滚子轴承		KR 72 PPXA
24	72	80	45.7	58.5	圆柱滚子轴承		NUKR 72 XA
24	72	80	26	48	圆柱滚子轴承		KR 72 PPA
